BZT260 AUTOMATIC SLIDING BOXING MACHINE
Short Description:
BZT260 AUTOMATIC SLIDING BOXING MACHINE is designed to align already fold-wrapped single square or cylinder shaped hard or soft candy products including bubble gum, chewing gum, toffee, caramel, milky candy into a stick, to fold the cardboard into a carton and then to pack the candies by the carton.
Special features
Programmable controller, HMI, integrated control
Vacuum-absorb inner and outer cardboard and automatic box making systems
Positioned glue spraying and packing system
No candy no paper, automatic stop when candy jam appears, automatic stop when wrapping material run out
Automatic defective products rejection system
Modular design, easy to maintain and clean
CE safety authorized
Norson glue hot-melt device
Schneider controlling system and screen
Vacuum pump and vacuum module
Output
300 pcs/min
30 boxes/min
Size Range
Single Product Dimensions(Round)
Φ: 15-21mm
Height: 8.5-10m
Products Per Box
5-10 pcs/box
Box Dimensions
Length: 53-120 mm
Width: 17-23 mm
Height: 17-23 mm
Special sizes upon request
Connected Load
20 kw
Utilities
Compressed air pressure: 0.5MPa
Compressed air supply: 0.7MPa
Wrapping Material
Already well shaped paper plate(Cardboard)
Machine Measurements
Length: 4000mm
Width: 1300mm
Height: 2350mm
MachineWeight
1500kg
It can be combined with SANKE’s fold wrapping machine BZW1000 to form an automatic boxing packing line
